Series AG-340 Magnetically Coupled Bottom Mixer
VQ-AG340
Agitator and mixer, power 0.25 to 5.5 kW, vessels 0.1 to 25 m³.
- POWER
- 0.25 to 5.5 kW
- VESSELS
- 0.1 to 25 m³
- SPEED
- 50 to 500 rpm
- MOUNTING
- Bottom flange, DN80 to DN150
Why it is specified
Sized on the process result rather than on the motor: blend time, solids suspension or heat transfer, whichever the duty actually is. The shaft and impellers are selected together so the critical speed stays clear of the running speed.
Typical applications
- Blending and homogenising
- Neutralisation tanks
- Solids suspension
- Storage tank roll-over
Options and executions
- Double mechanical seal with a barrier pot
- Folding impeller for manway installation
- Mixing calculation issued with the quotation
- Variable speed drive
The full table.
Figures cover the whole series. The variant table below narrows them to a part number.
PERFORMANCE
- Motor power
- 0.25 to 5.5 kW
- Output speed
- 50 to 500 rpm
- Vessel volume
- 0.1 to 25 m³
- Impeller diameter
- 100 to 350 mm
- Tip speed
- 1.5 to 5 m/s
MATERIALS
- Shaft
- None, bearing mounted impeller
- Impellers
- 1.4435 stainless steel, hydrofoil
- Mounting flange
- 1.4435, electropolished
- Shaft seal
- Sealless, magnetically coupled through the vessel wall
CONNECTIONS AND RATINGS
- Mounting
- Bottom flange, DN80 to DN150
- Vessel pressure
- Full vacuum to 10 bar
- Temperature at the seal
- -10 to +150 °C, steam sterilisable
- Enclosure
- IP55 motor
Stocked frame sizes.
| PART NUMBER | POWER | MOUNTING | VESSEL | IMPELLERS |
|---|---|---|---|---|
| VQ-AG340-10 | 0.25 kW | DN80 | to 2 m³ | One impeller |
| VQ-AG340-20 | 1.1 kW | DN100 | to 8 m³ | One impeller |
| VQ-AG340-30 | 5.5 kW | DN150 | to 25 m³ | One impeller |
AG-340, DS-AG-340
The datasheet is issued with the selection rather than downloaded blind, so the figures that arrive are the ones for your duty point. Ask for it with the quotation and it comes back as a PDF.
What is in it
- Selection data and the limits each figure applies at
- Dimensional drawings for every size in the variant table
- Materials of construction and the compatibility notes
- Installation, commissioning and maintenance intervals
- Spare parts list with the part numbers
Elsewhere in the catalogue.
HX-600
Fixed tube sheet shell-and-tube exchanger in stainless steel, for liquid-to-liquid and steam-to-liquid duty on process and utility systems.
AG-350
Flange-mounted top-entry agitator with a helical bevel gear unit and a hydrofoil impeller set, for blending, suspension and heat transfer duty in vessels from 1 to 40 m³.
HE-120
Heat exchanger, surface 0.5 to 90 m², duty 15 kW to 3.2 MW.
HE-180
Heat exchanger, surface 0.2 to 26 m², duty 5 kW to 900 kW.
Quote the AG-340 for your duty.
Send the process data and the line size. The quotation comes back with the selection, the calculation and the lead time on the stocked variants.
