Pumps
Centrifugal, positive displacement and sealless pumps for clean, viscous and aggressive duties, from DN25 to DN300.
The filters on this page are part of the design. Nothing is wired to a product database, so the result set does not change.
Pumps across the range.
Nine hundred line items across eleven pump types, held to a duty point rather than to a model number. Tell us flow, head, medium and temperature and the selection comes back with a curve, an NPSH margin and a materials note, not a catalogue page.
- FLOW
- 0.5 to 1,200 m³/h
- HEAD
- 6 to 220 m
- TEMPERATURE
- -40 to +350 °C
- CONNECTIONS
- DN25 to DN300
What sits under the heading.
- End-suction centrifugal
- Multistage
- Sealless magnetic drive
- Canned motor
- Progressing cavity
- Rotary lobe
- Air-operated diaphragm
- Peristaltic
- Vertical in-line
- Self-priming
- Drum and barrel
Two from this group, in full.
Each one carries its specification table, the variant list with part numbers, the options and the datasheet contents.
CP-150
Single-stage, back pull-out end-suction pump to EN 733, for clean and lightly loaded liquids in process, cooling and transfer duty.
MD-80
Close-coupled sealless centrifugal pump with a synchronous magnetic coupling, for aggressive, toxic and expensive media where a dynamic seal is not acceptable.
The variants behind the two series above.
CP-150, End-suction centrifugal pump
| PART NUMBER | SUCTION / DISCHARGE | CAPACITY | CASING MATERIAL | MOTOR |
|---|---|---|---|---|
| VQ-CP150-032-C | DN50 / DN32 | to 25 m³/h | Cast iron | 2.2 to 7.5 kW |
| VQ-CP150-050-C | DN65 / DN50 | to 70 m³/h | Cast iron | 4 to 18.5 kW |
| VQ-CP150-080-S | DN100 / DN80 | to 180 m³/h | 1.4408 | 11 to 45 kW |
| VQ-CP150-100-S | DN125 / DN100 | to 290 m³/h | 1.4408 | 22 to 90 kW |
| VQ-CP150-150-S | DN200 / DN150 | to 450 m³/h | 1.4408 | 45 to 160 kW |
MD-80, Sealless magnetic drive pump
| PART NUMBER | SUCTION / DISCHARGE | CAPACITY | WETTED MATERIAL | MOTOR |
|---|---|---|---|---|
| VQ-MD80-025-S | DN32 / DN25 | to 12 m³/h | 1.4571 | 0.37 to 3 kW |
| VQ-MD80-040-S | DN50 / DN40 | to 32 m³/h | 1.4571 | 1.5 to 11 kW |
| VQ-MD80-065-S | DN80 / DN65 | to 90 m³/h | 1.4571 | 5.5 to 30 kW |
| VQ-MD80-040-P | DN50 / DN40 | to 28 m³/h | PFA lined | 1.5 to 11 kW |
Send the duty for this group.
For pumps we need flow, head, temperature, connections. That is enough for a first selection.
Vanteq Industrial is a fictional company created for demonstration purposes. The products, part numbers and specifications shown here are illustrative and do not describe equipment that can be bought. The search and the filters are part of the design and are not connected to a product database.
