Filtration
Bag, cartridge, basket and self-cleaning filtration, with the housings, elements and differential pressure instruments that go with them.
The filters on this page are part of the design. Nothing is wired to a product database, so the result set does not change.
Filtration across the range.
A housing is half an answer. Every filtration selection is quoted with the element, the seal material, the differential pressure at the design flow and the change-out interval the duty implies, so the running cost is on the quotation and not discovered later.
- FLOW
- 1 to 400 m³/h
- RATING
- 0.5 to 800 micron
- DESIGN PRESSURE
- 6 to 16 bar
- MATERIALS
- 1.4301, 1.4404, 1.4571
What sits under the heading.
- Single bag housings
- Multi-bag housings
- Cartridge housings
- Basket strainers
- Y-strainers
- Duplex filters
- Self-cleaning filters
- Filter elements and bags
- Differential pressure gauges
Two from this group, in full.
Each one carries its specification table, the variant list with part numbers, the options and the datasheet contents.
FH-400
Stainless steel single-bag filter housing with a swing-bolt closure and an internal restrainer basket, for coarse and medium filtration on process and utility lines.
CF-250
Multi-round cartridge housing with a clamped closure, for fine and final filtration where the element is the specification and the housing is the frame around it.
The variants behind the two series above.
FH-400, Single bag filter housing
| PART NUMBER | BAG SIZE | CONNECTION | DESIGN FLOW | MATERIAL |
|---|---|---|---|---|
| VQ-FH400-01-050 | Size 1 | DN50 | to 20 m³/h | 1.4404 |
| VQ-FH400-01-080 | Size 1 | DN80 | to 35 m³/h | 1.4404 |
| VQ-FH400-02-080 | Size 2 | DN80 | to 60 m³/h | 1.4404 |
| VQ-FH400-02-100 | Size 2 | DN100 | to 80 m³/h | 1.4404 |
CF-250, Multi-cartridge filter housing
| PART NUMBER | ELEMENTS | CONNECTION | DESIGN FLOW | MATERIAL |
|---|---|---|---|---|
| VQ-CF250-03-050 | 3 elements | DN50 | to 14 m³/h | 1.4404 |
| VQ-CF250-05-050 | 5 elements | DN50 | to 23 m³/h | 1.4404 |
| VQ-CF250-07-080 | 7 elements | DN80 | to 32 m³/h | 1.4404 |
| VQ-CF250-12-080 | 12 elements | DN80 | to 55 m³/h | 1.4404 |
Send the duty for this group.
For filtration we need flow, rating, design pressure, materials. That is enough for a first selection.
